Z00607MA 5BL2
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC SENS GATE 600V 0.8A TO92-3
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.5808
≥1 USD $0.5808
≥10 USD $0.49632
≥100 USD $0.345312
≥500 USD $0.269632
≥1000 USD $0.219155
Inventory: 1334
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Surface Mount NO
Technical
Operating Temperature -40°C~110°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e3
Critical Rate of Rise of Commutation Voltage-Min 1.5V/us
Holding Current-Max 5mA
Triac Type Logic - Sensitive Gate
Critical Rate of Rise of Off-State Voltage-Min 10V/us
Leakage Current (Max) 0.1mA
Repetitive Peak Off-state Voltage 600V
Current - On State (It (RMS)) (Max) 800mA
Current - Gate Trigger (Igt) (Max) 5mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 9A 9.5A
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Voltage - Off State 600V
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-PBCY-T3
Pin Count 3
Base Part Number Z00607
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position BOTTOM
Subcategory TRIACs
HTS Code 8541.30.00.80
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Compliance
RoHS Status ROHS3 Compliant
