BTB24-800BRG
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC 800V 25A TO-220AB
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.364
≥1 USD $1.364
≥10 USD $1.098768
≥100 USD $0.904024
≥500 USD $0.764931
≥1000 USD $0.649035
≥3000 USD $0.61659
Inventory: 983
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Weight 6.000006g
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Additional Feature UL RECOGNIZED
Subcategory TRIACs
Voltage - Rated DC 800V
Current Rating 25A
Base Part Number BTB24
Pin Count 3
Number of Elements 1
Configuration Single
Case Connection MAIN TERMINAL 2
Max Repetitive Reverse Voltage (Vrrm) 800V
JEDEC-95 Code TO-220AB
RMS Current (Irms) 25A
Hold Current 80mA
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 250A 260A
Current - Gate Trigger (Igt) (Max) 50mA
Current - Hold (Ih) (Max) 80mA
Critical Rate of Rise of Off-State Voltage-Min 500V/us
Triac Type Standard
Critical Rate of Rise of Commutation Voltage-Min 10V/us
Dimensions
Height 15.9mm
Length 10.4mm
Width 4.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
