BTB10-800CWRG
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC ALTERNISTOR 800V TO220AB
PDF
/
Inventory: 2975
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Triac Type Alternistor - Snubberless
Critical Rate of Rise of Off-State Voltage-Min 500V/us
Leakage Current (Max) 1mA
Current - Gate Trigger (Igt) (Max) 35mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 100A 105A
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Trigger Device Type SNUBBERLESS TRIAC
Hold Current 35mA
RMS Current (Irms) 10A
JEDEC-95 Code TO-220AB
Case Connection MAIN TERMINAL 2
Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 3
Base Part Number BTB10
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 10A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Rated DC 800V
Subcategory TRIACs
HTS Code 8541.30.00.80
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series Snubberless?
Packaging Tube
Operating Temperature -40°C~125°C TJ
Physical
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
