BTA10-400BRG
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC 400V 10A TO220AB
PDF
/
Inventory: 4331
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Weight 6.000006g
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tube
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Subcategory TRIACs
Voltage - Rated DC 400V
Current Rating 10A
Base Part Number BTA10
Configuration Single
Max Repetitive Reverse Voltage (Vrrm) 400V
RMS Current (Irms) 10A
Hold Current 50mA
Trigger Device Type TRIAC
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 100A 105A
Current - Gate Trigger (Igt) (Max) 50mA
Leakage Current (Max) 0.5mA
Critical Rate of Rise of Off-State Voltage-Min 100V/us
Triac Type Standard
On-State Voltage-Max 1.4V
Critical Rate of Rise of Commutation Voltage-Min 10V/us
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
