ACS108-5SA
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC SENS GATE 500V 0.8A TO92-3
PDF
/
Buying Options
Total Price: USD $5.36
Unit Price: USD $5.36465
≥1 USD $5.36465
≥10 USD $4.40135
≥100 USD $4.26455
≥500 USD $4.1268
≥1000 USD $3.98905
Inventory: 1061
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Triac Type Logic - Sensitive Gate
Repetitive Peak Off-state Voltage 500V
Current - Gate Trigger (Igt) (Max) 10mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 7.3A 8A
Voltage - Gate Trigger (Vgt) (Max) 1V
Voltage - Off State 500V
Trigger Device Type TRIAC
Hold Current 25mA
RMS Current (Irms) 800mA
Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 3
Base Part Number ACS108
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position BOTTOM
Additional Feature WITH BUILT IN CLAMPING STRUCTURE AND GATE LEVEL SHIFTER DRIVER
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series ACS?/A.S.D?
Packaging Bulk
Operating Temperature -30°C~125°C TJ
Physical
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
