ACS102-5TA
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC SENS GATE 500V 0.2A TO92-3
PDF
/
Inventory: 1690
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Technical
Operating Temperature -30°C~125°C TJ
Packaging Bulk
Series ASD?
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Matte Tin (Sn)
Additional Feature WITH BUILT IN CLAMPING STRUCTURE AND GATE LEVEL SHIFTER DRIVER
Subcategory TRIACs
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 250
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number ACS102
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Configuration Single
RMS Current (Irms) 200mA
Hold Current 20mA
Trigger Device Type SNUBBERLESS TRIAC
Voltage - Off State 500V
Voltage - Gate Trigger (Vgt) (Max) 900mV
Triac Type Logic - Sensitive Gate
Non-Repetitive Pk On-state Cur 8 A
Repetitive Peak Off-state Voltage 500V
Current - On State (It (RMS)) (Max) 200mA
On-State Current-Max 200A
Current - Gate Trigger (Igt) (Max) 5mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 7.3A 8A
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
