MAC97A8RLRP
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
Tape & Box (TB) Through Hole Logic - Sensitive Gate Single TRIAC 8A @ 60Hz 5mA 600V -40C~110C TJ
PDF
/
Inventory: 2805
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Surface Mount NO
Number of Pins 3
Technical
Operating Temperature -40°C~110°C TJ
Packaging Tape & Box (TB)
Published 2005
JESD-609 Code e1
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Additional Feature HIGH RELIABILITY
Subcategory TRIACs
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 240
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number MAC97
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Configuration Single
RMS Current (Irms) 600mA
Hold Current 10mA
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Voltage - Off State 600V
Voltage - Gate Trigger (Vgt) (Max) 2V
Current - Non Rep. Surge 50, 60Hz (Itsm) 8A @ 60Hz
Current - Gate Trigger (Igt) (Max) 5mA
Current - On State (It (RMS)) (Max) 600mA
Repetitive Peak Off-state Voltage 600V
Triac Type Logic - Sensitive Gate
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
