MAC97A4G
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
Bulk Through Hole Logic - Sensitive Gate Single TRIAC 8A @ 60Hz 5mA 200V -40C~110C TJ
PDF
/
Buying Options
Total Price: USD $6.93
Unit Price: USD $6.927386
≥1 USD $6.927386
≥10 USD $6.535267
≥100 USD $6.165348
≥500 USD $5.816368
≥1000 USD $5.487137
Inventory: 7849
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 6.35mm
Length 5.1816mm
Height 5.334mm
Technical
RMS On-state Current-Max 0.6A
Triac Type Logic - Sensitive Gate
Leakage Current (Max) 0.1mA
Current - Gate Trigger (Igt) (Max) 5mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 8A @ 60Hz
Voltage - Gate Trigger (Vgt) (Max) 2V
Voltage - Off State 200V
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Hold Current 10mA
Channel Type Bidirectional
RMS Current (Irms) 600mA
Max Repetitive Reverse Voltage (Vrrm) 200V
Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number MAC97
Time@Peak Reflow Temperature-Max (s) 40
Current Rating 800mA
Peak Reflow Temperature (Cel) 260
Terminal Position BOTTOM
Voltage - Rated DC 200V
Subcategory TRIACs
Additional Feature HIGH RELIABILITY
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e1
Published 2005
Packaging Bulk
Operating Temperature -40°C~110°C TJ
Physical
Weight 4.535924g
Number of Pins 3
Surface Mount NO
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 4 days ago)
