MAC4DCN-001
RoHS
/
Package TO-251-3 Short Leads, IPak, TO-251AA
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
Triacs THY 4A 800V TRIAC
PDF
/
Inventory: 7216
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-251-3 Short Leads, IPak, TO-251AA
Surface Mount NO
Number of Pins 3
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tube
Published 2006
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory TRIACs
Peak Reflow Temperature (Cel) 240
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number MAC4
Pin Count 4
Qualification Status Not Qualified
Number of Elements 1
Configuration Single
Case Connection MAIN TERMINAL 2
RMS Current (Irms) 4A
Hold Current 35mA
Trigger Device Type TRIAC
Voltage - Off State 800V
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 40A @ 60Hz
Current - On State (It (RMS)) (Max) 4A
Repetitive Peak Off-state Voltage 800V
Leakage Current (Max) 2mA
Critical Rate of Rise of Off-State Voltage-Min 500V/us
Triac Type Standard
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
