MAC15A10T

ON Semiconductor
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description TRIAC 800V 15A TO220AB
PDF
/
Inventory: 4558
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3

Technical

Operating Temperature -40°C~125°C TJ
Packaging Tube
Published 2008
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory TRIACs
Base Part Number MAC15
Pin Count 3
Number of Elements 1
Configuration Single
Case Connection MAIN TERMINAL 2
Max Repetitive Reverse Voltage (Vrrm) 800V
JEDEC-95 Code TO-220AB
RMS Current (Irms) 15A
Hold Current 40mA
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Voltage - Off State 800V
Voltage - Gate Trigger (Vgt) (Max) 2V
Current - Non Rep. Surge 50, 60Hz (Itsm) 150A @ 60Hz
Current - Gate Trigger (Igt) (Max) 50mA
Leakage Current (Max) 2mA
Triac Type Standard

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
