MAC12SM
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
Tube Through Hole Logic - Sensitive Gate Single TRIAC 15V/us 5mA 600V -40C~110C TJ
PDF
/
Inventory: 8565
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-220-3
Surface Mount NO
Number of Pins 3
Technical
Operating Temperature -40°C~110°C TJ
Packaging Tube
Published 2009
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory TRIACs
Peak Reflow Temperature (Cel) 240
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number MAC12
Pin Count 3
Qualification Status Not Qualified
Number of Elements 1
Configuration Single
Case Connection MAIN TERMINAL 2
JEDEC-95 Code TO-220AB
RMS Current (Irms) 12A
Hold Current 10mA
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Voltage - Off State 600V
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 90A @ 60Hz
Current - Gate Trigger (Igt) (Max) 5mA
Current - On State (It (RMS)) (Max) 12A
Repetitive Peak Off-state Voltage 600V
Critical Rate of Rise of Off-State Voltage-Min 15V/us
Triac Type Logic - Sensitive Gate
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
