Q6010N5TP
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC 600V 10A TO263
PDF
/
Buying Options
Total Price: USD $4.14
Unit Price: USD $4.144825
≥1 USD $4.144825
≥200 USD $1.654254
≥500 USD $1.599112
≥1000 USD $1.571541
Inventory: 8115
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Triac Type Standard
Critical Rate of Rise of Off-State Voltage-Min 200V/us
Leakage Current (Max) 2mA
Current - Gate Trigger (Igt) (Max) 50mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 100A 120A
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Hold Current 50mA
RMS Current (Irms) 10A
Case Connection MAIN TERMINAL 2
Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 10A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Voltage - Rated DC 600V
Subcategory TRIACs
HTS Code 8541.30.00.80
Additional Feature HIGH RELIABILITY
Terminal Finish Matte Tin (Sn)
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e3
Published 2004
Packaging Tube
Operating Temperature -40°C~125°C TJ
Physical
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
