Q2016NH3TP
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC ALTERNISTOR 200V 16A TO263
PDF
/
Inventory: 8074
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tube
Published 2004
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Additional Feature HIGH RELIABILITY
HTS Code 8541.30.00.80
Voltage - Rated DC 200V
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Current Rating 16A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 4
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 1
Configuration Single
Case Connection MAIN TERMINAL 2
RMS Current (Irms) 16A
Hold Current 35mA
Trigger Device Type ALTERNISTOR TRIAC
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 167A 200A
Current - Gate Trigger (Igt) (Max) 20mA
Current - Hold (Ih) (Max) 35mA
Triac Type Alternistor - Snubberless
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
