LJ4004D8TP
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC 4A 400V TO-252 D-PAK
PDF
/
Buying Options
Total Price: USD $2.08
Unit Price: USD $2.075695
≥1 USD $2.075695
≥200 USD $0.82844
≥750 USD $0.800869
≥1500 USD $0.78774
Inventory: 1488
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Series LJxx04xx
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Matte Tin (Sn)
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 40
Configuration Single
Trigger Device Type TRIAC
Voltage - Off State 400V
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 40A 48A
Current - Gate Trigger (Igt) (Max) 20mA
Current - On State (It (RMS)) (Max) 4A
Triac Type Logic - Sensitive Gate
Compliance
RoHS Status ROHS3 Compliant
