L4006L8
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Isolated Tab
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC SENS GATE 400V 6A TO220
PDF
/
Inventory: 2307
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Critical Rate of Rise of Commutation Voltage-Min 2V/us
Holding Current-Max 15mA
RMS On-state Current-Max 6A
Triac Type Logic - Sensitive Gate
Critical Rate of Rise of Off-State Voltage-Min 40V/us
Leakage Current (Max) 0.02mA
Repetitive Peak Off-state Voltage 600V
Current - Hold (Ih) (Max) 20mA
Current - Gate Trigger (Igt) (Max) 10mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 50A 60A
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Hold Current 20mA
RMS Current (Irms) 6A
JEDEC-95 Code TO-220AB
Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 10
Current Rating 6A
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 260
Voltage - Rated DC 400V
Subcategory TRIACs
HTS Code 8541.30.00.80
Additional Feature UL RECOGNIZED
Terminal Finish Matte Tin (Sn)
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code no
JESD-609 Code e3
Published 2004
Packaging Bulk
Operating Temperature -40°C~110°C TJ
Physical
Package / Case TO-220-3 Isolated Tab
Mounting Type Through Hole
Mount Through Hole
