L2006D8RP
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
Tape & Reel (TR) Surface Mount Logic - Sensitive Gate Single TRIAC 50A 60A 10mA 1.3V -40C~110C TJ
PDF
/
Inventory: 6917
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Technical
Operating Temperature -40°C~110°C TJ
Packaging Tape & Reel (TR)
Published 2004
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish MATTE TIN
Additional Feature HIGH RELIABILITY
HTS Code 8541.30.00.80
Voltage - Rated DC 200V
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Reach Compliance Code unknown
Current Rating 6A
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 3
JESD-30 Code R-PSSO-G2
Qualification Status Not Qualified
Number of Elements 1
Configuration Single
Case Connection MAIN TERMINAL 2
JEDEC-95 Code TO-252AA
RMS Current (Irms) 6A
Hold Current 20mA
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 50A 60A
Current - Gate Trigger (Igt) (Max) 10mA
Current - Hold (Ih) (Max) 20mA
Triac Type Logic - Sensitive Gate
RMS On-state Current-Max 6A
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
