L2004D6TP
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
Tube Surface Mount Logic - Sensitive Gate Single TRIAC 33A 40A 5mA 1.3V -40C~110C TJ
PDF
/
Inventory: 4250
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
RMS On-state Current-Max 4A
Triac Type Logic - Sensitive Gate
Current - Hold (Ih) (Max) 10mA
Current - Gate Trigger (Igt) (Max) 5mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 33A 40A
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Trigger Device Type 4 QUADRANT LOGIC LEVEL TRIAC
Hold Current 10mA
RMS Current (Irms) 4A
JEDEC-95 Code TO-252AA
Case Connection MAIN TERMINAL 2
Configuration Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 10
Current Rating 4A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Voltage - Rated DC 200V
HTS Code 8541.30.00.80
Additional Feature HIGH RELIABILITY
Terminal Finish MATTE TIN
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2004
Packaging Tube
Operating Temperature -40°C~110°C TJ
Physical
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
