CQ3P-40N
RoHS
/
Package /
Category Discrete Semiconductor Products / Thyristors - TRIACs
Description
TRIAC 40A 800V TO-3
PDF
/
Inventory: 7612
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Surface Mount NO
Technical
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) Vendor Undefined
Number of Terminations 3
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8541.30.00.80
Subcategory TRIACs
Terminal Position UPPER
Terminal Form SOLDER LUG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
JESD-30 Code O-MUFM-D3
Qualification Status Not Qualified
Operating Temperature (Max) 125°C
Operating Temperature (Min) -40°C
Number of Elements 1
Configuration SINGLE
Case Connection ISOLATED
Trigger Device Type TRIAC
Repetitive Peak Off-state Voltage 800V
Leakage Current (Max) 3mA
Critical Rate of Rise of Off-State Voltage-Min 500V/us
RMS On-state Current-Max 40A
Holding Current-Max 50mA
DC Gate Trigger Current-Max 50mA
DC Gate Trigger Voltage-Max 2.5V
Critical Rate of Rise of Commutation Voltage-Min 5V/us
Compliance
RoHS Status Non-RoHS Compliant
