VS-ST230C12C0
RoHS
RoHS compliant
RoHS compliantPackage TO-200AB, A-PUK
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR PHASE CONT 1200V 410A A-PUK
PDF
/
Buying Options
Total Price: USD $59.44
Unit Price: USD $59.444
≥1 USD $59.444
≥10 USD $53.86993
≥100 USD $48.297418
Inventory: 104
Minimum: 1
-
+
Technical Details
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case TO-200AB, A-PUK
Number of Pins 2
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Published 2014
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Current Rating 410A
Base Part Number ST230C*C
Circuit Type SCR
Max Repetitive Reverse Voltage (Vrrm) 1.2kV
RMS Current (Irms) 780A
Hold Current 600mA
Trigger Device Type SCR
Voltage - Gate Trigger (Vgt) (Max) 3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 5700A 5970A
Current - Gate Trigger (Igt) (Max) 150mA
Current - Hold (Ih) (Max) 600mA
Current - On State (It (RMS)) (Max) 780A
SCR Type Standard Recovery
Voltage - On State (Vtm) (Max) 1.69V
Current - Off State (Max) 30mA
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
