RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR PHASE CONT 1200V 16A TO220AB
PDF
/
Buying Options
Total Price: USD $3.94
Unit Price: USD $3.9406
≥1 USD $3.9406
≥10 USD $3.23285
≥100 USD $3.13215
≥500 USD $3.03145
≥1000 USD $2.9298
Inventory: 19448
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 2
Supplier Device Package TO-220AB
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2009
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Base Part Number 16TTS*
RMS Current (Irms) 16A
Hold Current 100mA
Voltage - Off State 1.2kV
Voltage - Gate Trigger (Vgt) (Max) 2V
Current - Non Rep. Surge 50, 60Hz (Itsm) 200A @ 50Hz
Current - Gate Trigger (Igt) (Max) 60mA
Current - Hold (Ih) (Max) 100mA
Current - On State (It (RMS)) (Max) 16A
Current - On State (It (AV)) (Max) 10A
SCR Type Standard Recovery
Voltage - On State (Vtm) (Max) 1.4V
Current - Off State (Max) 500μA
Compliance
RoHS Status Non-RoHS Compliant
