X0403DF 1AA2
RoHS
RoHS compliant
RoHS compliantPackage TO-202 No Tab
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR 4A 400V TO202-3
PDF
/
Inventory: 2233
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Circuit Commutated Turn-off Time-Nom 50 μs
Holding Current-Max 5mA
Repetitive Peak Reverse Voltage 400V
Current - Off State (Max) 5μA
Critical Rate of Rise of Off-State Voltage-Min 30V/us
Voltage - On State (Vtm) (Max) 1.8V
SCR Type Sensitive Gate
Non-Repetitive Pk On-state Cur 25 A
Current - On State (It (AV)) (Max) 900mA
Leakage Current (Max) 0.2mA
Repetitive Peak Off-state Voltage 400V
Current - On State (It (RMS)) (Max) 1.35A
Current - Hold (Ih) (Max) 5mA
Current - Gate Trigger (Igt) (Max) 200μA
Current - Non Rep. Surge 50, 60Hz (Itsm) 30A 33A
Voltage - Gate Trigger (Vgt) (Max) 800mV
Voltage - Off State 400V
Trigger Device Type SCR
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSIP-T3
Base Part Number X0403
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) 225
Terminal Position SINGLE
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Terminal Finish MATTE TIN
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Surface Mount NO
Package / Case TO-202 No Tab
Mounting Type Through Hole
Supply Chain
Factory Lead Time 5 Weeks
