X0202MA 2BL2
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR 1.25A 600V TO-92
PDF
/
Buying Options
Total Price: USD $0.76
Unit Price: USD $0.7568
≥1 USD $0.7568
≥10 USD $0.65912
≥100 USD $0.456016
≥500 USD $0.38104
≥1000 USD $0.324289
Inventory: 106084
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Holding Current-Max 5mA
Repetitive Peak Reverse Voltage 600V
Current - Off State (Max) 5μA
Critical Rate of Rise of Off-State Voltage-Min 10V/us
Voltage - On State (Vtm) (Max) 1.45V
SCR Type Sensitive Gate
Non-Repetitive Pk On-state Cur 25 A
Current - On State (It (AV)) (Max) 800mA
Leakage Current (Max) 0.5mA
Repetitive Peak Off-state Voltage 600V
Current - On State (It (RMS)) (Max) 1.25A
Current - Hold (Ih) (Max) 5mA
Current - Gate Trigger (Igt) (Max) 200μA
Current - Non Rep. Surge 50, 60Hz (Itsm) 22.5A 25A
Voltage - Gate Trigger (Vgt) (Max) 800mV
Voltage - Off State 600V
Trigger Device Type SCR
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-PBCY-T3
Base Part Number X0202
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position BOTTOM
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Additional Feature HIGH RELIABILITY
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Box (TB)
Operating Temperature -40°C~125°C
Physical
Surface Mount NO
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 7 Weeks
