TYN606RG
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR 600V 6A TO220AB
PDF
/
Buying Options
Total Price: USD $1.12
Unit Price: USD $1.1176
≥1 USD $1.1176
≥10 USD $0.899008
≥100 USD $0.712448
≥500 USD $0.603874
≥1000 USD $0.49192
≥3000 USD $0.463082
Inventory: 1199
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Number of Pins 3
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory Silicon Controlled Rectifiers
Voltage - Rated DC 600V
Terminal Position SINGLE
Current Rating 6A
Base Part Number TYN606
Pin Count 3
Number of Elements 1
Configuration SINGLE
Max Repetitive Reverse Voltage (Vrrm) 600V
JEDEC-95 Code TO-220AB
RMS Current (Irms) 6A
Hold Current 30mA
Trigger Device Type SCR
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 70A 73A
Current - Gate Trigger (Igt) (Max) 15mA
Current - Hold (Ih) (Max) 30mA
Leakage Current (Max) 2mA
Current - On State (It (AV)) (Max) 3.8A
SCR Type Standard Recovery
Voltage - On State (Vtm) (Max) 1.6V
Critical Rate of Rise of Off-State Voltage-Min 200V/us
Current - Off State (Max) 10μA
RMS On-state Current-Max 6A
Circuit Commutated Turn-off Time-Nom 70 μs
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
