TXN692RG
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR STD 600V 20A 25MA TO-220
PDF
/
Inventory: 1818
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Current - Off State (Max) 10μA
Voltage - On State (Vtm) (Max) 1.4V
SCR Type Standard Recovery
Current - On State (It (AV)) (Max) 13A
Current - On State (It (RMS)) (Max) 20A
Current - Hold (Ih) (Max) 40mA
Current - Gate Trigger (Igt) (Max) 25mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 250A 260A
Voltage - Off State 800V
Base Part Number TXN692
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Supplier Device Package TO-220AB
Package / Case TO-220-3
Mounting Type Through Hole
