TS420-600B
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR 4A 200UA 600V DPAK
PDF
/
Buying Options
Total Price: USD $0.34
Unit Price: USD $0.3439
≥1 USD $0.3439
≥10 USD $0.28215
≥100 USD $0.2736
≥500 USD $0.26505
≥1000 USD $0.25555
Inventory: 139670
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Current - Off State (Max) 5μA
Voltage - On State (Vtm) (Max) 1.6V
SCR Type Sensitive Gate
Current - On State (It (RMS)) (Max) 4A
Current - Hold (Ih) (Max) 5mA
Current - Gate Trigger (Igt) (Max) 200μA
Current - Non Rep. Surge 50, 60Hz (Itsm) 30A 33A
Voltage - Gate Trigger (Vgt) (Max) 800mV
Trigger Device Type SCR
Hold Current 5mA
RMS Current (Irms) 4A
Max Repetitive Reverse Voltage (Vrrm) 600V
Configuration SINGLE
Number of Elements 1
JESD-30 Code R-PSSO-G2
Pin Count 3
Base Part Number TS420
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 2.5A
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position SINGLE
Voltage - Rated DC 600V
Subcategory Silicon Controlled Rectifiers
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 15 Weeks
