TS110-7UF
RoHS
RoHS compliant
RoHS compliantPackage DO-221AA, SMB Flat Leads
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR SENS 700V 1.25A SMBFLAT-3L
PDF
/
Buying Options
Total Price: USD $0.87
Unit Price: USD $0.8712
≥1 USD $0.8712
≥10 USD $0.7128
≥100 USD $0.554312
≥500 USD $0.469867
≥1000 USD $0.382765
≥3000 USD $0.360325
Inventory: 1475
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Current - Off State (Max) 1μA
Critical Rate of Rise of Off-State Voltage-Min 15V/us
Voltage - On State (Vtm) (Max) 1.4V
SCR Type Sensitive Gate
Current - On State (It (AV)) (Max) 800mA
Leakage Current (Max) 0.1mA
Current - Gate Trigger (Igt) (Max) 100μA
Current - Non Rep. Surge 50, 60Hz (Itsm) 25A 27A
Voltage - Gate Trigger (Vgt) (Max) 800mV
Voltage - Off State 700V
Trigger Device Type SCR
Hold Current 2mA
RMS Current (Irms) 1.25A
Max Repetitive Reverse Voltage (Vrrm) 700V
Base Part Number TS110
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Subcategory Silicon Controlled Rectifiers
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Digi-Reel?
Operating Temperature -40°C~125°C
Physical
Number of Pins 3
Package / Case DO-221AA, SMB Flat Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 7 months ago)
