TN5015H-6G-TR
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
HIGH TEMPERATURE 50A SCRS
PDF
/
Buying Options
Total Price: USD $1.4
Unit Price: USD $1.3992
≥1 USD $1.3992
≥10 USD $1.15896
≥100 USD $0.922768
≥500 USD $0.833149
Inventory: 20076
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Current - Off State (Max) 10μA
Voltage - On State (Vtm) (Max) 1.65V
SCR Type Standard Recovery
Current - On State (It (AV)) (Max) 30A
Current - On State (It (RMS)) (Max) 50A
Current - Hold (Ih) (Max) 60mA
Current - Gate Trigger (Igt) (Max) 15mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 493A 450A
Voltage - Gate Trigger (Vgt) (Max) 1.3V
Voltage - Off State 600V
Base Part Number TN5015
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 15 Weeks
