P0111MN 5AA4
RoHS
RoHS compliant
RoHS compliantPackage TO-261-4, TO-261AA
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR 0.8A 600V 25MA SOT-223
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
≥10 USD $0.2728
≥100 USD $0.163416
≥500 USD $0.151325
Inventory: 1481
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Holding Current-Max 5mA
Repetitive Peak Reverse Voltage 600V
Current - Off State (Max) 10μA
Critical Rate of Rise of Off-State Voltage-Min 80V/us
Voltage - On State (Vtm) (Max) 1.95V
SCR Type Sensitive Gate
Non-Repetitive Pk On-state Cur 8 A
Current - On State (It (AV)) (Max) 500mA
Leakage Current (Max) 0.1mA
Repetitive Peak Off-state Voltage 600V
Current - On State (It (RMS)) (Max) 800mA
Current - Hold (Ih) (Max) 5mA
Current - Gate Trigger (Igt) (Max) 25μA
Current - Non Rep. Surge 50, 60Hz (Itsm) 7A 8A
Voltage - Gate Trigger (Vgt) (Max) 800mV
Voltage - Off State 600V
Trigger Device Type SCR
Case Connection ANODE
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G4
Pin Count 4
Base Part Number P0111
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case TO-261-4, TO-261AA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
