P0102DA 1AA3
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR 0.8A 400V 200UA TO-92-3
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.30448
≥100 USD $0.153648
≥500 USD $0.136136
≥1000 USD $0.105943
≥3000 USD $0.09482
Inventory: 1366
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Holding Current-Max 5mA
Repetitive Peak Reverse Voltage 400V
Current - Off State (Max) 10μA
Critical Rate of Rise of Off-State Voltage-Min 75V/us
Voltage - On State (Vtm) (Max) 1.95V
SCR Type Sensitive Gate
Non-Repetitive Pk On-state Cur 8 A
Current - On State (It (AV)) (Max) 500mA
Leakage Current (Max) 0.1mA
Repetitive Peak Off-state Voltage 400V
Current - On State (It (RMS)) (Max) 800mA
Current - Hold (Ih) (Max) 5mA
Current - Gate Trigger (Igt) (Max) 200μA
Current - Non Rep. Surge 50, 60Hz (Itsm) 7A 8A
Voltage - Gate Trigger (Vgt) (Max) 800mV
Voltage - Off State 400V
Trigger Device Type SCR
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-PBCY-T3
Pin Count 3
Base Part Number P0102
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position BOTTOM
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Surface Mount NO
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Supply Chain
Factory Lead Time 5 Weeks
