P0102BA 1AA3
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SCR 0.8A 200V 200UA TO-92
PDF
/
Inventory: 9560
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Holding Current-Max 5mA
Repetitive Peak Reverse Voltage 200V
Current - Off State (Max) 10μA
Critical Rate of Rise of Off-State Voltage-Min 75V/us
Voltage - On State (Vtm) (Max) 1.95V
SCR Type Sensitive Gate
Non-Repetitive Pk On-state Cur 8 A
Current - On State (It (AV)) (Max) 500mA
Leakage Current (Max) 6mA
Repetitive Peak Off-state Voltage 200V
Current - On State (It (RMS)) (Max) 800mA
Current - Hold (Ih) (Max) 5mA
Current - Gate Trigger (Igt) (Max) 200μA
Current - Non Rep. Surge 50, 60Hz (Itsm) 7A 8A
Voltage - Gate Trigger (Vgt) (Max) 800mV
Voltage - Off State 200V
Trigger Device Type SCR
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code O-PBCY-W3
Base Part Number P0102
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form WIRE
Terminal Position BOTTOM
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Surface Mount NO
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
