2N6509
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
SILICON CONTROLLED RECTIFIER
PDF
/
Buying Options
Total Price: USD $1.04
Unit Price: USD $1.0374
≥1 USD $1.0374
≥10 USD $0.8512
≥100 USD $0.8246
≥500 USD $0.798
≥1000 USD $0.7714
Inventory: 9004
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Repetitive Peak Reverse Voltage 800V
SCR Type Standard Recovery
Current - On State (It (AV)) (Max) 16A
Repetitive Peak Off-state Voltage 800V
Current - On State (It (RMS)) (Max) 25A
Current - Hold (Ih) (Max) 40mA
Current - Gate Trigger (Igt) (Max) 30mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 250A @ 60Hz
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Voltage - Off State 800V
Trigger Device Type SCR
JEDEC-95 Code TO-220AB
Case Connection ANODE
Configuration SINGLE
Number of Elements 1
Qualification Status COMMERCIAL
JESD-30 Code R-PSFM-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 240
Terminal Position SINGLE
Terminal Finish TIN LEAD
Number of Terminations 3
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Physical
Surface Mount NO
Package / Case TO-220-3
Mounting Type Through Hole
