T627022054DN
RoHS
RoHS compliant
RoHS compliantPackage DO-200AA, A-PUK
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
Bulk Stud Mount Standard Recovery SINGLE SCR 4000A @ 60Hz 150mA 200V -40C~125C
PDF
/
Inventory: 9308
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Repetitive Peak Reverse Voltage 200V
Current - Off State (Max) 25mA
Voltage - On State (Vtm) (Max) 2.1V
SCR Type Standard Recovery
Non-Repetitive Pk On-state Cur 4000 A
Current - On State (It (AV)) (Max) 200A
Leakage Current (Max) 25mA
Repetitive Peak Off-state Voltage 200V
Current - Gate Trigger (Igt) (Max) 150mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 4000A @ 60Hz
Voltage - Gate Trigger (Vgt) (Max) 3V
Voltage - Off State 200V
Trigger Device Type SCR
RMS Current (Irms) 315A
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
Subcategory Silicon Controlled Rectifiers
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2000
Packaging Bulk
Operating Temperature -40°C~125°C
Physical
Number of Pins 3
Package / Case DO-200AA, A-PUK
Mounting Type Stud Mount
Mount Stud
Supply Chain
Factory Lead Time 6 Weeks
