MCR22-6RLRAG
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
Cut Tape (CT) Through Hole Sensitive Gate SINGLE SCR 25V/us 200muA 40mus 1.7V
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.2641
≥1 USD $0.2641
≥10 USD $0.2166
≥100 USD $0.20995
≥500 USD $0.2033
≥1000 USD $0.19665
Inventory: 41608
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Number of Pins 3
Technical
Operating Temperature -40°C~110°C
Packaging Cut Tape (CT)
Published 2006
JESD-609 Code e1
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Subcategory Silicon Controlled Rectifiers
Voltage - Rated DC 200V
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) 260
Current Rating 1.5A
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCR22
Pin Count 3
Number of Elements 1
Configuration SINGLE
Forward Voltage 1.7V
Max Repetitive Reverse Voltage (Vrrm) 400V
RMS Current (Irms) 1.5A
Hold Current 5mA
Trigger Device Type SCR
Voltage - Off State 400V
Voltage - Gate Trigger (Vgt) (Max) 800mV
Current - Non Rep. Surge 50, 60Hz (Itsm) 15A @ 60Hz
Current - Gate Trigger (Igt) (Max) 200μA
Leakage Current (Max) 0.2mA
Non-Repetitive Pk On-state Cur 15 A
SCR Type Sensitive Gate
Voltage - On State (Vtm) (Max) 1.7V
Critical Rate of Rise of Off-State Voltage-Min 25V/us
Current - Off State (Max) 10μA
Circuit Commutated Turn-off Time-Nom 40 μs
Dimensions
Height 5.33mm
Length 5.2mm
Width 4.19mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
