2N5060RLRM
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Thyristors - SCRs
Description
THYRISTOR SCR 0.8A 30V TO-92
PDF
/
Inventory: 9676
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Circuit Commutated Turn-off Time-Nom 10 μs
Current - Off State (Max) 10μA
Voltage - On State (Vtm) (Max) 1.7V
SCR Type Sensitive Gate
Non-Repetitive Pk On-state Cur 10 A
Current - On State (It (AV)) (Max) 510mA
Leakage Current (Max) 0.01mA
Current - On State (It (RMS)) (Max) 800mA
Current - Gate Trigger (Igt) (Max) 200μA
Current - Non Rep. Surge 50, 60Hz (Itsm) 10A @ 60Hz
Voltage - Gate Trigger (Vgt) (Max) 800mV
Voltage - Off State 30V
Trigger Device Type SCR
Hold Current 5mA
RMS Current (Irms) 800mA
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number 2N5060
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 240
Terminal Position BOTTOM
Subcategory Silicon Controlled Rectifiers
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Published 2008
Packaging Tape & Box (TB)
Operating Temperature -40°C~110°C
Physical
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
Mount Through Hole
