VSKH170-16D25
RoHS
/
Package 3-MAGN-A-PAK?
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Bulk Series Connection - SCR/Diode Chassis Mount Diodes SCR Module 5100A 5350A 200mA 3V 130C
PDF
/
Inventory: 9365
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case 3-MAGN-A-PAK?
Technical
Packaging Bulk
Published 2009
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 130°C
Min Operating Temperature -40°C
Current Rating 170A
Base Part Number KH170
Circuit Type Diodes
RMS Current (Irms) 377A
Hold Current 500mA
Voltage - Off State 1.6kV
Voltage - Gate Trigger (Vgt) (Max) 3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 5100A 5350A
Current - Gate Trigger (Igt) (Max) 200mA
Current - Hold (Ih) (Max) 500mA
Current - On State (It (RMS)) (Max) 377A
Structure Series Connection - SCR/Diode
Current - On State (It (AV)) (Max) 170A
Number of SCRs, Diodes 1 SCR, 1 Diode
Compliance
RoHS Status Non-RoHS Compliant
