VS-VSKL41/10
RoHS
RoHS compliant
RoHS compliantPackage ADD-A-PAK (3 + 4)
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Bulk Series Connection - SCR/Diode Chassis Mount Diodes SCR Module 850A 890A 150mA 1kV -40C~125C TJ
PDF
/
Inventory: 7032
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case ADD-A-PAK (3 + 4)
Number of Pins 5
Weight 110.000005g
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2012
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Current Rating 45A
Circuit Type Diodes
Max Repetitive Reverse Voltage (Vrrm) 1kV
RMS Current (Irms) 100A
Hold Current 200mA
Trigger Device Type SCR
Voltage - Gate Trigger (Vgt) (Max) 2.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 850A 890A
Current - Gate Trigger (Igt) (Max) 150mA
Current - Hold (Ih) (Max) 200mA
Current - On State (It (RMS)) (Max) 100A
Structure Series Connection - SCR/Diode
Number of SCRs, Diodes 1 SCR, 1 Diode
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
