VS-VSKH56/12
RoHS
RoHS compliant
RoHS compliantPackage ADD-A-PAK (3 + 4)
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
SCR Modules 1200 Volt 60 Amp 890 Amp IFSM
PDF
/
Buying Options
Total Price: USD $31.66
Unit Price: USD $31.66109
≥1 USD $31.66109
≥10 USD $29.868957
≥100 USD $28.178259
≥500 USD $26.583264
≥1000 USD $25.078552
Inventory: 1146
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case ADD-A-PAK (3 + 4)
Number of Pins 5
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2012
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Current Rating 60A
Circuit Type Diodes
Max Repetitive Reverse Voltage (Vrrm) 1.2kV
RMS Current (Irms) 135A
Hold Current 200mA
Trigger Device Type SCR
Voltage - Gate Trigger (Vgt) (Max) 2.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 1200A 1256A
Current - Gate Trigger (Igt) (Max) 150mA
Current - Hold (Ih) (Max) 200mA
Current - On State (It (RMS)) (Max) 135A
Structure Series Connection - SCR/Diode
Number of SCRs, Diodes 1 SCR, 1 Diode
Dimensions
Height 30mm
Length 92mm
Width 22.6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
