VS-VSKH136/04PBF
RoHS
RoHS compliant
RoHS compliantPackage INT-A-PAK (3 + 4)
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
SCR Modules 400 Volt 135 Amp
PDF
/
Buying Options
Total Price: USD $157.46
Unit Price: USD $157.461349
≥1 USD $157.461349
≥195 USD $62.82883
≥495 USD $60.72819
≥1005 USD $59.690999
Inventory: 8249
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Chassis Mount, Screw
Mounting Type Chassis Mount
Package / Case INT-A-PAK (3 + 4)
Number of Pins 5
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2012
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Reach Compliance Code unknown
Current Rating 135A
Circuit Type Diodes
Max Repetitive Reverse Voltage (Vrrm) 400V
RMS Current (Irms) 300A
Hold Current 200mA
Trigger Device Type SCR
Voltage - Gate Trigger (Vgt) (Max) 2.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 3200A 3360A
Current - Gate Trigger (Igt) (Max) 150mA
Current - Hold (Ih) (Max) 200mA
Current - On State (It (RMS)) (Max) 300A
Structure Series Connection - SCR/Diode
Number of SCRs, Diodes 1 SCR, 1 Diode
Compliance
RoHS Status ROHS3 Compliant
