RoHS
RoHS compliant
RoHS compliantPackage 8-PACE-PAK
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
MOD BRIDGE SCR 25A 1000V PACEPAK
PDF
/
Inventory: 9427
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Number of SCRs, Diodes 4 SCRs
Structure Bridge, Single Phase - All SCRs
Current - Gate Trigger (Igt) (Max) 60mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 357A 375A
Voltage - Gate Trigger (Vgt) (Max) 2V
Voltage - Off State 1kV
Trigger Device Type SCR
Hold Current 130mA
RMS Current (Irms) 25A
Circuit Type Thyristors
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 25A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2013
Packaging Bulk
Operating Temperature -40°C~125°C TJ
Physical
Package / Case 8-PACE-PAK
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 12 Weeks
