T560N12TOFXPSA1
RoHS
RoHS compliant
RoHS compliantPackage DO-200AA, A-PUK
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
PHASE CONTROL THYRISTOR
PDF
/
Inventory: 8027
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Number of SCRs, Diodes 1 SCR
Current - On State (It (AV)) (Max) 559A
Structure Single
Current - On State (It (RMS)) (Max) 809A
Current - Hold (Ih) (Max) 300mA
Current - Gate Trigger (Igt) (Max) 200mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 8000A @ 50Hz
Voltage - Gate Trigger (Vgt) (Max) 2V
Voltage - Off State 1.8kV
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Package / Case DO-200AA, A-PUK
Mounting Type Chassis Mount
