T7H8047504DN
RoHS
RoHS compliant
RoHS compliantPackage TO-200 Variation
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
SCR PHASE CTRL MOD 400V 750A
PDF
/
Inventory: 2234
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Number of SCRs, Diodes 1 SCR
Repetitive Peak Reverse Voltage 400V
Current - On State (It (AV)) (Max) 750A
Structure Single
Current - On State (It (RMS)) (Max) 1180A
Current - Gate Trigger (Igt) (Max) 150mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 9600A 10500A
Voltage - Gate Trigger (Vgt) (Max) 3V
Voltage - Off State 400V
Trigger Device Type SCR
RMS Current (Irms) 1.18kA
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UNSPECIFIED
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2007
Packaging Bulk
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 3
Package / Case TO-200 Variation
Mounting Type Chassis Mount
Mount Chassis Mount
Supply Chain
Factory Lead Time 6 Weeks
