LD431650
RoHS
RoHS compliant
RoHS compliantPackage POW-R-BLOK? Module
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
SCR MODULE DUAL ISO 1600V 500A
PDF
/
Buying Options
Total Price: USD $139.92
Unit Price: USD $139.92
≥1 USD $139.92
Inventory: 75
Minimum: 1
-
+
Technical Details
Technical
Terminal Form UNSPECIFIED
Current Rating 500A
Pin Count 7
JESD-30 Code R-XXFM-X7
Number of Elements 2
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Case Connection ISOLATED
RMS Current (Irms) 900A
Trigger Device Type SCR
Voltage - Off State 1.6kV
Voltage - Gate Trigger (Vgt) (Max) 3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 16300A 17000A
Current - Gate Trigger (Igt) (Max) 200mA
On-State Current-Max 500000A
Current - On State (It (RMS)) (Max) 900A
Structure Series Connection - All SCRs
Repetitive Peak Off-state Voltage 1600V
Leakage Current (Max) 80mA
Critical Rate of Rise of Off-State Voltage-Min 1000V/us
Repetitive Peak Reverse Voltage 1600V
Number of SCRs, Diodes 2 SCRs
Desc. of Screw Terminals A-K-AK
Desc. of Quick-Connects 2G-2GR
Repetitive Peak Off-state Leakage Current-Max 80000μA
Terminal Position UNSPECIFIED
Subcategory Silicon Controlled Rectifiers
Additional Feature UL RECOGNIZED
Number of Terminations 7
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2002
Packaging Bulk
Operating Temperature -40°C~130°C TJ
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Physical
Number of Pins 3
Package / Case POW-R-BLOK? Module
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Supply Chain
Factory Lead Time 24 Weeks
