CM4308A2
RoHS
/
Package POW-R-BLOK? Module
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
SCR MOD DUAL 800V 25A
PDF
/
Inventory: 4987
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case POW-R-BLOK? Module
Number of Pins 7
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2000
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
HTS Code 8541.30.00.80
Subcategory Silicon Controlled Rectifiers
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Current Rating 25A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 7
Qualification Status Not Qualified
Number of Elements 2
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Case Connection ISOLATED
RMS Current (Irms) 39A
Trigger Device Type SCR
Voltage - Off State 800V
Voltage - Gate Trigger (Vgt) (Max) 3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 445A 490A
Current - Gate Trigger (Igt) (Max) 50mA
On-State Current-Max 25000A
Current - On State (It (RMS)) (Max) 39A
Structure Series Connection - All SCRs
Repetitive Peak Off-state Voltage 800V
Leakage Current (Max) 4mA
Non-Repetitive Pk On-state Cur 490 A
Critical Rate of Rise of Off-State Voltage-Min 500V/us
Repetitive Peak Reverse Voltage 800V
Number of SCRs, Diodes 2 SCRs
Desc. of Screw Terminals A-K-AK
Desc. of Quick-Connects 2G-2GR
Repetitive Peak Off-state Leakage Current-Max 4000μA
Compliance
RoHS Status RoHS Compliant
