CD631815C
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
POWEREX CD631815C SCR, MOD, 150A, 1.8KV, POW-R-BLOK
PDF
/
Inventory: 9325
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Screw
Mounting Type Screw Mount
Package / Case Module
Number of Pins 7
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2012
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
RMS Current (Irms) 235A
Hold Current 150mA
Trigger Device Type SCR
Voltage - Off State 1.8kV
Voltage - Gate Trigger (Vgt) (Max) 2.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 5400A @ 50Hz
Current - On State (It (RMS)) (Max) 235A
Structure Series Connection - All SCRs
Current - On State (It (AV)) (Max) 150A
Number of SCRs, Diodes 2 SCRs
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
