CD631615C
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Bulk Series Connection - All SCRs Screw Mount SCR SCR Module 5400A @ 50Hz 150A 2.5V -40C~125C TJ
PDF
/
Inventory: 6112
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Technical
Number of SCRs, Diodes 2 SCRs
Current - On State (It (AV)) (Max) 150A
Structure Series Connection - All SCRs
Current - On State (It (RMS)) (Max) 235A
Current - Non Rep. Surge 50, 60Hz (Itsm) 5400A @ 50Hz
Voltage - Gate Trigger (Vgt) (Max) 2.5V
Voltage - Off State 1.6kV
Trigger Device Type SCR
Hold Current 150mA
RMS Current (Irms) 235A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2012
Packaging Bulk
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 7
Package / Case Module
Mounting Type Screw Mount
Mount Screw
Supply Chain
Factory Lead Time 20 Weeks
