CD430890B
RoHS
RoHS compliant
RoHS compliantPackage POW-R-BLOK? Module
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
SCR MOD ISO DUAL 800V 90A
PDF
/
Inventory: 7341
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Chassis Mount
Mounting Type Chassis Mount
Package / Case POW-R-BLOK? Module
Technical
Operating Temperature -40°C~125°C TJ
Packaging Bulk
Published 2009
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 7
HTS Code 8541.30.00.80
Subcategory Silicon Controlled Rectifiers
Terminal Position UPPER
Terminal Form UNSPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 7
JESD-30 Code R-XUFM-X7
Qualification Status Not Qualified
Number of Elements 2
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Case Connection ISOLATED
RMS Current (Irms) 150A
Hold Current 250mA
Trigger Device Type SCR
Voltage - Off State 800V
Voltage - Gate Trigger (Vgt) (Max) 3V
Current - Non Rep. Surge 50, 60Hz (Itsm) 2000A 2100A
Current - Gate Trigger (Igt) (Max) 150mA
On-State Current-Max 90000A
Current - On State (It (RMS)) (Max) 150A
Structure Series Connection - All SCRs
Repetitive Peak Off-state Voltage 800V
Leakage Current (Max) 10mA
Current - On State (It (AV)) (Max) 95A
Non-Repetitive Pk On-state Cur 2100 A
Repetitive Peak Reverse Voltage 800V
Number of SCRs, Diodes 2 SCRs
Desc. of Screw Terminals A-K-AK
Desc. of Quick-Connects 2G-K-AK
Compliance
RoHS Status RoHS Compliant
