VTOF70-08IO7
RoHS
RoHS compliant
RoHS compliantPackage FO-T-A
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
RECT BRIDGE 3PH 800V FO-T-A
PDF
/
Inventory: 8279
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Desc. of Quick-Connects 3AK-CA-CK
Desc. of Screw Terminals 0
RMS On-state Current-Max 36A
Number of SCRs, Diodes 6 SCRs
Repetitive Peak Reverse Voltage 800V
Non-Repetitive Pk On-state Cur 550 A
Leakage Current (Max) 5mA
Repetitive Peak Off-state Voltage 800V
Structure Bridge, 3-Phase - All SCRs
Current - Hold (Ih) (Max) 200mA
On-State Current-Max 70000A
Current - Gate Trigger (Igt) (Max) 100mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 550A 600A
Voltage - Gate Trigger (Vgt) (Max) 1.5V
Voltage - Off State 800V
Trigger Device Type SCR
Hold Current 200mA
Circuit Type SCR
Case Connection ISOLATED
Configuration 3 PHASE BRIDGE WITH BUILT-IN FREE-WHEELING DIODE
Number of Elements 6
Qualification Status Not Qualified
JESD-30 Code R-XUFM-D11
Base Part Number VTOF
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 70A
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form SOLDER LUG
Terminal Position UPPER
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Additional Feature FAST
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Number of Terminations 11
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Published 2000
Packaging Bulk
Operating Temperature -40°C~125°C TJ
Physical
Package / Case FO-T-A
Mounting Type Chassis Mount
Mount Chassis Mount
