VHF36-08IO5

IXYS
RoHS
RoHS RoHS compliant
Package X118
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description Thyristor SCR Module 800V 350A 6-Pin FO-F-A
PDF
/
Inventory: 7817
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Number of SCRs, Diodes 2 SCRs, 2 Diodes
Current - On State (It (AV)) (Max) 36A
Structure Bridge, Single Phase - SCRs/Diodes (Layout 1)
Current - Hold (Ih) (Max) 100mA
Current - Gate Trigger (Igt) (Max) 65mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 320A 350A
Voltage - Gate Trigger (Vgt) (Max) 1V
Voltage - Off State 800V
Hold Current 100mA
Circuit Type SCR
Base Part Number VHF36
Current Rating 40A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2000
Packaging Bulk
Operating Temperature -40°C~125°C TJ

Physical

Number of Pins 6
Package / Case X118
Mounting Type Chassis Mount
Mount Chassis Mount, Screw

Supply Chain

Factory Lead Time 20 Weeks
