VHF28-16IO5
RoHS
RoHS compliant
RoHS compliantPackage X118
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
BRIDGE RECT SGL PHASE 1600V 32A
PDF
/
Buying Options
Total Price: USD $24.68
Unit Price: USD $24.68142
≥1 USD $24.68142
≥10 USD $23.28436
≥100 USD $21.96638
≥500 USD $20.723
≥1000 USD $19.55
≥3000 USD $18.4434
Inventory: 8126
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 31.6mm
Length 63mm
Height 21mm
Technical
Desc. of Quick-Connects 2G-2AK-CA-CK
Desc. of Screw Terminals 0
RMS On-state Current-Max 23A
Number of SCRs, Diodes 2 SCRs, 2 Diodes
Non-Repetitive Pk On-state Cur 330 A
Leakage Current (Max) 0.3mA
Structure Bridge, Single Phase - SCRs/Diodes (Layout 1)
On-State Current-Max 28000A
Current - Gate Trigger (Igt) (Max) 65mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 300A 330A
Voltage - Gate Trigger (Vgt) (Max) 1V
Trigger Device Type SCR
Hold Current 100mA
Max Repetitive Reverse Voltage (Vrrm) 1.6kV
Peak Reverse Current 300μA
Average Rectified Current 28A
Forward Voltage 1.6V
Circuit Type SCR
Forward Current 32A
Case Connection ISOLATED
Output Current 32A
Configuration BRIDGE, HALF-CONTROLLED, COMMON CATHODE WITH BUILT-IN FREE-WHEELING DIODE
Number of Elements 2
Qualification Status Not Qualified
Base Part Number VHF28
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Current Rating 32A
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form SOLDER LUG
Terminal Position UPPER
Voltage - Rated DC 1.6kV
Subcategory Silicon Controlled Rectifiers
HTS Code 8541.30.00.80
Terminal Finish Nickel (Ni)
Number of Terminations 6
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Published 2000
Packaging Bulk
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 6
Package / Case X118
Mounting Type Chassis Mount
Mount Chassis Mount, Panel, Screw
Supply Chain
Factory Lead Time 20 Weeks
