VGO36-16IO7
RoHS
/
Package ECO-PAC1
Category Discrete Semiconductor Products / Thyristors - SCRs - Modules
Description
Diode Rectifier Bridge Single 1.6KV 36A 6-Pin ECO-PAC 1
PDF
/
Buying Options
Total Price: USD $18.93
Unit Price: USD $18.9288
≥1 USD $18.9288
≥10 USD $16.8212
≥100 USD $14.712368
≥500 USD $12.554573
Inventory: 121
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 30.3mm
Length 47mm
Height 9mm
Technical
Desc. of Quick-Connects 2G-2AK-CA-CK
Desc. of Screw Terminals 0
Number of SCRs, Diodes 2 SCRs, 2 Diodes
Current - On State (It (AV)) (Max) 40A
Structure Bridge, Single Phase - SCRs/Diodes (Layout 3)
Current - Gate Trigger (Igt) (Max) 65mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 320A 350A
Voltage - Gate Trigger (Vgt) (Max) 1V
Voltage - Off State 1.6kV
Trigger Device Type SCR
Hold Current 100mA
Peak Non-Repetitive Surge Current 350A
Max Repetitive Reverse Voltage (Vrrm) 1.6kV
Peak Reverse Current 300μA
Average Rectified Current 36A
Forward Voltage 1.45V
Max Surge Current 350A
Max Reverse Leakage Current 300μA
Case Connection ISOLATED
Configuration BRIDGE, HALF-CONTROLLED
Number of Elements 1
Qualification Status Not Qualified
Pin Count 6
Base Part Number VGO36
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form UNSPECIFIED
Terminal Position UPPER
Subcategory Silicon Controlled Rectifiers
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Published 2010
Packaging Bulk
Operating Temperature -40°C~125°C TJ
Physical
Number of Pins 6
Package / Case ECO-PAC1
Mounting Type Chassis Mount
Mount Chassis Mount, Screw
Supply Chain
Factory Lead Time 5 Weeks
